. Learn more about Condition:
- Used, Excellent Condition
Specifications:
- Manufacturer: Jim Dunlop Manufacturing, Inc. (USA)
- Country of Origin: Made in the USA
- Type: Analog wah-wah pedal (based on the classic GCB95 Cry Baby circuit)
- Controls: Variable Q (adjusts bandpass intensity/response), Volume Boost (up to +15dB), foot rocker for wah sweep
- Switching: Auto-return / switchless (engages on foot pressure, disengages when released; buffered bypass)
- Boost Switch: Side-mounted kick switch
- Power: 9V DC adapter or single 9V battery (~1.8–9mA draw)
- Impedance: Input 1MΩ, Output 1kΩ
- Frequency Range: Aggressive sweep (~390Hz–2kHz)
- Dimensions / Weight: Approx. 10″ x 4″ x 2.5″; ~2.6 lbs (heavy-duty metal enclosure)
- Connectors: 1 x 1/4″ input, 1 x 1/4″ output
